Synology FlashStation FS3600 24-Bay 2.5" SATA SSD NAS

Name: Synology FlashStation FS3600 24-Bay 2.5" SATA SSD NAS
Brand: Synology
SKU: PRD-202607-5231

Key Features24 x 2.

Quote on request

✓ Available to order · supplied & installed in Malaysia

Request Quotation WhatsApp Ask a question

Genuine unit through the authorised channel — manufacturer warranty
Itemised quotation within 1 working day, B2B invoicing
Delivery nationwide — installation available for enterprise gear

Key specifications
Form factor	Rackmount

Full specifications ↓

Product details

Key Features 24 x 2.5" SAS/SATA Drive Bays 2.1 GHz Intel Xeon D-1567 Twelve-Core 16GB of DDR4 ECC Registered RAM 2 x 10GbE \| 4 x Gigabit Ethernet 3 x USB 3.0 Type-A \| 1 x Expansion RAID 0, 1, 5, 6, 10, F1, JBOD & Basic Up to 193,000 4K IOPS Random Writes Connect RX1217sas & RX2417sas Expansion AES-NI Hardware Encryption Engine Synology DiskStation Manager OS
CPU
CPU Model	Intel Xeon D-1567
CPU Quantity	1
CPU Architecture	64-bit
CPU Frequency	12-core 2.1 (base) / 2.7 (turbo) GHz
Hardware Encryption Engine (AES-NI)	✓
Memory
System Memory	16 GB DDR4 ECC RDIMM
Memory Module Pre-installed	16 GB (16 GB x 1)
Total Memory Slots	4
Maximum Memory Capacity	128 GB (32 GB x 4)
Notes	Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. For more information on memory upgrade limitations, visit here. For more information on the recommended memory configurations, visit here.
Storage
Drive Bays	24
Maximum Drive Bays with Expansion Unit	48 (RX1217sas x 2) / 72 (FX2421* x 2)
Compatible Drive Type* (See all supported drives)	2.5" SAS HDD* 2.5" SAS SSD* 2.5" SATA SSD
Hot Swappable Drive*	✓
Notes	2.5" SAS HDD and 2.5" SAS SSD only indicate the drive types that may be compatible with Synology devices. For supported drive models, please refer to the device’s compatibility list. "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port	4 (with Link Aggregation / Failover support)
RJ-45 10GbE LAN Port	2 (with Link Aggregation / Failover support)
USB 3.2 Gen 1 Port*	2
Expansion Port	1
Notes	The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe
PCIe Expansion	1 x Gen3 x8 slot (x8 link)
File System
Internal Drives	Btrfs EXT4
External Drives	Btrfs EXT4 EXT3 FAT NTFS HFS+ exFAT
Notes	exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center.
Appearance
Form Factor (RU)	2U
Size (Height x Width x Depth)	88 mm x 482 mm x 724 mm
Weight	14.9 kg
Rack Installation Support*	4-post 19" rack (Synology Rail Kit - RKS-02)
Notes	The rail kit is sold separately
Others
System Fan	80 mm x 80 mm x 4 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
Easy Replacement System Fan	✓
Power Recovery	✓
Noise Level*	57 dB(A)
Scheduled Power On / Off	✓
Wake on LAN / WAN	✓
Power Supply Unit / Adapter	500 W
Redundant Power Supply	✓
AC Input Power Voltage	100V to 240V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	258.23 W (Access) 127.99 W (HDD Hibernation)
British Thermal Unit	881.12 BTU/hr (Access) 436.72 BTU/hr (HDD Hibernation)
Notes	Power consumption is measured when it is fully loaded with HGST 1.8TB HUC101818CS4204 hard drive(s). Noise Level Testing Environment: Fully loaded with Toshiba 600GB AL14SEB060N hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
Operating Temperature	0°C to 35°C (32°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Relative Humidity	5% to 95% RH
Certification
FCC CE BSMI EAC CCC VCCI RCM
Warranty
5 Years
Notes	The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
Main Unit X 1 Accessory Pack X 1 AC Power Cord X 2 Quick Installation Guide X 1
Optional Accessories
DDR4 ECC RDIMM: D4RD-2666-16G/D4RD-2666-32G Expansion Units: FX2421/RX1217sas 2.5" SATA SSD: SAT5210 25GbE Network Interface Card: E25G21-F2 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1 Rail Kit Sliding: RKS-02 VisualStation: VS360HD Surveillance Device License Pack
Notes	It is required to use D4RD-2666-16G with identical memory modules of the same capacity and frequency. For more information, visit here. Expansion Unit FX2421 can only be used with identical expansion units.
