ACER Projector S1386WH | XGA | 3600 LUMENS | DLP PROJECTOR | HDMI, VGA PORT, AUDIO-IN, RCA
ACER Projector S1386WH | XGA | 3600 LUMENS | DLP PROJECTOR | HDMI, VGA PORT, AUDIO-IN, RCA - ImageNative Resolution 1280 x 800Maximum Resolution 1920 x 1200Stan...
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Resolution | 1024 x 768 XGA MP |
| Type | Education |
Product details
Native Resolution 1280 x 800
Maximum Resolution 1920 x 1200
Standard Mode Brightness 3600 lm
Native Aspect Ratio 16:10
Compatible Aspect Ratio 16:9 - 4:3
Contrast Ratio 20,000:1
Throw Ratio 0.52 (2209.80 mm@980 mm)
Digital Zoom 2x
Vertical Keystone Correction -40°/+40°
Maximum Vertical Sync 120 Hz
Maximum Horizontal Sync 100 kHz
Minimum Vertical Sync 24 Hz
Minimum Horizontal Sync 15 kHz
Colour Supported 1.07 Billion Colors (30-bit)
Projection Lens
Maximum Lens Aperture f/2.80
Maximum Focal Length 7.51 mm
Minimum Diagonal Image Size 914.40 mm
Maximum Diagonal Image Size 7.62 m (300")
Minimum Projection Distance 400 mm
Maximum Projection Distance 3.40 m
Optical Zoom 1x
Lamp
Lamp Type OSRAM
Number of Lamps 1
Lamp Power 220 W
Normal Mode Lamp Life 5000 Hour
Economy Mode Lamp Life 6000 Hour
ExtremeEco Mode Lamp Life 10000 Hour
Interfaces/Ports
HDMI Yes
Composite Video Yes
Number of VGA Inputs 1
VGA In Yes
Number of VGA Outputs 1
VGA Out Yes
Number Of Audio Inputs 1
Number Of Audio Outputs 1
Audio Line In Yes
Audio Line Out Yes
Total Number of HDMI Ports 1
Technical Information
Projection System DLP
Projection Method Ceiling, Front Rea,r Rear Ceiling
Video Compatibility (EDTV, HDTV, NTSC, PAL, SDTV, SECAM)
Computer Compatibility: Mac PC, Windows PC
Audio
Number of Speakers 1
Speaker Output Power 16 W
Speaker Output Mode Mono
Power Description
Power Supply 100 V AC ~ 240 V AC
Input Voltage 120 V AC, 230 V AC
Operating Power Consumption 270 W
Physical Characteristics
Fan Noise 24 dB Approximate Economy Mode
32 dB Approximate Standard Mode
Weight (Approximate) 3.10 kg
Form Factor Ceiling Mountable
Height 113.7 mm
Width 313 mm
Depth 255.3 mm
Miscellaneous
Optional Accessories
- 3D Glasses (MC.JFZ11.00B)
- Lamp (MC.JQH11.001)
- WirelessProjection-Kit (UWA3) (MC.JG811.00E)
- WirelessCAST (MWA3) (MC.JKY11.007)
- Ceiling Mount (MC.JLC11.003)
- WirelessHD-Kit (MC.JKY11.009)
Warranty
2 YEARS
(Lamp 1yr or 1K Hours)
- Delivery & professional installation
- Configuration & migration
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Camera Specs | |
|---|---|
| Resolution | 1024 x 768 XGA MP |
| Storage Media Specs | |
|---|---|
| Type | Education |
Related products
You recently viewed
Frequently asked questions
How much does the ACER Projector S1386WH | XGA | 3600 LUMENS | DLP PROJECTOR | HDMI, VGA PORT, AUDIO-IN, RCA cost?
This product is quoted per project. Send us your requirements and we will prepare a quotation.
Is this product available in Malaysia?
Yes — available to order. Supplied and installed nationwide by RYZEN ESOLUTIONS (M) SDN BHD.
Who manufactures the ACER Projector S1386WH | XGA | 3600 LUMENS | DLP PROJECTOR | HDMI, VGA PORT, AUDIO-IN, RCA?
It is manufactured by Acer. We supply genuine units with manufacturer warranty.
Do you provide installation and support?
Yes — we design, install, configure and support this product as part of a complete solution. Ask us about maintenance packages.
