APC Smart-UPS, Line Interactive, 1000VA, Tower, 230V, 8x IEC C13 outlets, SmartSlot, AVR, LCD (SMT1000I)
APC · UPS

APC Smart-UPS, Line Interactive, 1000VA, Tower, 230V, 8x IEC C13 outlets, SmartSlot, AVR, LCD (SMT1000I)

APC Smart-UPS, Line Interactive, 1000VA, Tower, 230V, 8x IEC C13 outlets, SmartSlot, AVR, LCD (SMT1000I) - SpecificationsOverview

Quote on request
✓ Available to order · supplied & installed in Malaysia
Request Quotation WhatsApp Ask a question
  • Genuine unit through the authorised channel — manufacturer warranty
  • Itemised quotation within 1 working day, B2B invoicing
  • Delivery nationwide — installation available for enterprise gear
Key specifications
Capacity 1000VA VA
Full specifications ↓

Product details

Specifications

Overview
PresentationIntelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Lead timeUsually Ships within 2 Weeks

Main
Main Input Voltage230 V
Other Input Voltage220 V
240 V
Main Output Voltage230 V
Other Output Voltage220 V
240 V
Rated power in W700 W
Rated power in VA1000 VA
Input Connection TypeIEC 320 C14
output connection type8 IEC 320 C13
2 IEC Jumpers
Battery typeLead-acid battery
Provided equipmentUSB cable
Documentation CD
Installation guide
Smart UPS signalling RS-232 cable

Batteries & Runtime
Additional informationConfigurable for 220 : 230 or 240 nominal output voltage
Extended runtime0
Number of battery filled slots0
Number of battery free slots0
Battery recharge time3 h
Number of battery replacement quantity1
Battery life3…5 year(s)
Replacement batteryRBC6
action_new_window
Battery charger power88 W rated

General
Number of power module filled slots0
Number of power module free slots0
RedundantNo

Physical
ColourBlack
height21.9 cm
Width17.1 cm
Depth43.9 cm
Net weight18.86 kg
Mounting locationFront
Mounting preferenceNo preference
Mounting modeNot rack-mountable
Two post mountable0
USB compatibleNo

Input
Input voltage limits151...302 V adjustable
160...286 V
Network frequency50/60 Hz +/- 3 Hz auto-sensing

Output
Harmonic distortionLess than 5 % at full load
Maximum configurable power in VA1000 VA
Maximum configurable power in W700 W
UPS typeLine interactive
Wave typeSine wave
Output frequency47...53 Hz for 50 Hz nominal sync to mains
57...63 Hz for 60 Hz nominal sync to mains

Conformance
product certificationsCE
EAC
RCM
VDE
StandardsEN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018

Environmental
Acoustic level41 dBA
Heat dissipation100 Btu/h
Operating altitude0...10000 ft
ambient air temperature for operation0…40 °C
Ambient air temperature for storage-15…45 °C
Storage altitude0.00…15240.00 m
Relative humidity0…95 %
Storage Relative Humidity0…95 %

Communications & Management
control panelMultifunction LCD status and control console
Emergency power offOptional
Free slots1
AlarmAlarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge Protection and Filtering
Surge energy rate459 J
Noise suppressionFull time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Packing Units
Unit Type of Package 1PCE
Number of Units in Package 11
Package 1 Height37.6 cm
Package 1 Width32.8 cm
Package 1 Length59.5 cm
Package 1 Weight22.77 kg
Unit Type of Package 2P12
Number of Units in Package 29
Package 2 Height124 cm
Package 2 Width80 cm
Package 2 Length120 cm
Package 2 Weight
