| Model | MF752Cdw | | Print | Printing Method Colour Laser Beam Printing
Print Speed
A4 33 / 33 ppm (Mono / Colour)
Letter 35 / 35 ppm (Mono / Colour)
2-Sided 29 / 29 ppm (Mono / Colour)
Print Resolution 600 x 600 dpi
Print Quality with Image Refinement Technology 1,200 (eq.) x 1,200 dpi (eq.)
Warm-Up Time (From Power On) 14 sec or less
First Print Out Time (FPOT) (Approx.)
A4 7.1 / 7.1 sec (Mono / Colour)
Letter 7.0 / 7.0 sec (Mono / Colour)
Recovery Time (From Sleep Mode) 5.3 sec or less
Print Language UFR II, PCL 6
Auto Duplex Print Yes
Print Margins Top/Bottom/Left/Right Margin: 5 mm
Top/Bottom/Left/Right Margin: 10 mm (Envelope)
Supported File Format for USB Direct Print JPEG, TIFF, PDF | | Copy | Copy Speed A4
A4 33 / 33 ppm (Mono / Colour)
Letter 35 / 35 ppm (Mono / Colour)
Copy Resolution 600 x 600 dpi
First Copy Out Time (FCOT) (Approx.)
A4 7.6 / 8.8 sec (Mono / Colour)
Letter 7.4 / 8.6 sec (Mono / Colour)
Maximum Number of Copies Up to 999 copies
Reduce/Enlargement 25 - 400% in 1% increments
Copy Features Frame Erase, Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy | | Scan | Scan Resolution
Optical Platen glass: up to 600 x 600 dpi
Feeder: up to 300 x 300 dpi
Driver Enhanced Up to 9,600 x 9,600 dpi
Scan Type Colour Contact Image Sensor
Maximum Scan Size
Platen Glass Up to 216.0 x 297 mm
Feeder Up to 216.0 x 355.6 mm
Scan Speed*1 1-Sided: 50 ipm (mono), 40 ipm (colour)
2-Sided: 100 ipm (mono), 80 ipm (colour)
Colour Depth 24-bit
Pull Scan Yes, USB and Network
Push Scan (Scan To PC) with MF Scan Utility Yes, USB and Network
Scan To USB (via USB Host 2.0) Yes
Scan To Cloud MF Scan Utility
Scan Driver Compatibility TWAIN, WIA | | Send | SEND Method SMB, Email, FTP
Colour Mode Full Colour, Greyscale, Monochrome
Scan Resolution 300 x 600 dpi
File Format JPEG, TIFF, PDF, Compact PDF, PDF (OCR) | | Paper Handling | Auto Document Feeder (ADF) Duplex ADF: 50 sheets (80 g/m2)
Available Paper Size for ADF A4, B5, A5, A6, Letter, Legal, Statement, Business Card
(min. 48.0 x 85.0 mm to max. 216.0 x 355.6 mm)
Paper Input
(Based on 80 g/m2)
Standard Cassette 250 sheets
Multi-Purpose Tray 50 sheets
Optional Paper Feeder 550 sheets
Maximum Paper Input Capacity 850 sheets
Paper Output
150 sheets
Paper Sizes
Standard Cassette A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Envelope (COM10, Monarch, C5, DL)
Custom (min. 98.0 x 148.0 mm to max. 216.0 x 356.0 mm)
Multi-Purpose Tray A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card, Envelope (COM10, Monarch, C5, DL)
Custom (min. 76.0 x 127.0 mm to max. 216.0 x 356.0 mm)
Optional Paper Feeder A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal
Custom (min. 100.0 x 148.0 mm to max. 216.0 x 356.0 mm)
Available Paper Size for Auto Duplex Print A4, B5, A5, Letter, Legal, Executive, Foolscap, Indian Legal
Paper Types Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope
Paper Weight
ADF 50 to 105 g/m2
Standard Cassette /
Optional Paper Feeder 60 to 200 g/m2
Multi-Purpose Tray 60 to 200 g/m2 | | Connectivity & Software | Standard Interfaces
Wired USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T
Wireless Wi-Fi 802.11b/g/n
(Infrastructure mode, WPS, Direct Connection)
Network Protocol
Print LPD, RAW, WSD-Print (IPv4, IPv6)
Scan Email, SMB, WSD-Scan (IPv4, IPv6), FTP
TCP/IP Application Services Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6)
Management SNMPv1, SNMPv3 (IPv4,IPv6)
Network Security
Wired IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC, TLS 1.3
Wireless Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES),
WPA-EAP (AES), WPA2-EAP (AES), IEEE802.1x
Access Point Mode: WPA2-PSK (AES)
Other Features Department ID, Secure Print, Application Library
Mobile Solution Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print
Address Book LDAP
Compatible Operating Systems*3 Windows®, Windows Server®, Mac® OS, Linux*4
Software Included Printer driver, Scanner driver, MF Scan Utility, Toner Status | | General | Device Memory 1 GB
Display WVGA Colour LCD 5-inch Touch Screen Display
Dimensions (W x D x H) (Approx.) 425 x 461 x 430 mm
Weight (Approx.) 21.7 kg
Power Consumption (Approx.)
Maximum (Operation) 1,380 W or less
Average (Operation) 700 W
Average (Standby) 24.0 W
Average (Sleep) 1.0 W (USB/Wired/Wireless)
Operating Environment
Temperature 10 - 30°C
Humidity 20% - 80% RH (no condensation)
Power Requirements AC 220-240 V (±10%), 50/60 Hz (±2 Hz)
Toner Cartridge*5
Standard Cartridge 069 BK: 2,100 pages (bundled: 2,100 pages)
Cartridge 069 CMY: 1,900 pages (bundled: 1,100 pages)
High Cartridge 069H BK: 7,600 pages
Cartridge 069H CMY: 5,500 pages
Monthly Duty Cycle*6 50,000 pages | | * Prices, Features, Package Content and Specifications are subject to change without prior notification.* |
|
