| Model |
D9L20A |
| Functions |
Functions: Print, copy, scan, fax
Multitasking supported: Yes |
| Print |
Print speed black:
ISO: Up to 24 ppm
Draft: Up to 36 ppm
Print speed color:
ISO:Up to 20 ppm
Draft:Up to 36 ppm
First page out (ready):
Black: As fast as 10 sec
Color: As fast as 11 sec
Recommended monthly page volume: 250 to 2000
Print technology: HP Thermal Inkjet
Print quality (best)
Color: Up to 2400 x 1200 optimized dpi on HP Advance Photo Paper 600 x 600 dpi input
Black: Up to 1200 x 1200 optimized dpi on plain paper from 600 x 600 input dpi
Display: 4.3" CGD touchscreen
Processor speed: 1.2 Ghz
Number of print cartridges: 4 (1 each black, cyan, magenta, yellow)
Print languages: HP PCLXL (PCL6), native PDF, HP Postscript Level 3 emulation
Automatic paper sensor: Yes |
| Scan |
Scanner type: Flatbed, ADF
Scan file format:
Scan File Type supported by Software: Bitmap (.bmp), JPEG (.jpg), PDF (.pdf), PNG (.png), Rich Text (.rtf), Searchable PDF (.pdf), Text (.txt), TIFF (.tif)
Scan resolution, optical: Up to 1200 dpi
Bit depth: 24-bit
Scan size (flatbed), maximum: 216 x 356 mm
Scan size (ADF), maximum: 215 x 355mm
Scan size ADF (minimum): 127 x 127 mm
Scan speed (normal, A4):
Up to 19 ipm (200 ppi, b&w)
up to 8 ipm (200 ppi, color)
Automatic document feeder capacity: Standard, 50 sheets
Digital sending standard features:
Scan-to E-mail
Fax Archive to E-mail
File formats, supported:
PDF
TIFF
JPEG
Scan input modes: Front-panel scan, copy, fax, or from software |
| Copy |
Copy speed (draft):
Black: Up to 37 cpm
Color: Up to 37 cpm
Copy resolution (black text): Up to 600 dpi
Copy resolution (color text and graphics): Up to 600 dpi
Copy reduce / enlarge settings: 25 to 400%
Copies, maximum: Up to 99 copies |
| Fax |
Faxing: Yes, color
Fax transmission speed: 4 sec per page
Fax memory: Up to 100 pages
Broadcast locations: 20 |
| Connectivity |
HP ePrint capability: Yes
Mobile printing capability: HP ePrint, Apple AirPrint™, Android OS Enablement Printing, Mopria™-certified [4]
(Wireless operations are compatible with 2.4 GHz operations only. App or software and HP ePrint account registration may also be required. Some features require purchase of an optional accessory. Learn more at http://www.hp.com/go/mobileprinting)
Wireless capability: Yes
Connectivity, standard:
1 USB 2.0
1 Host USB
1 Ethernet
1 Wireless 802.11b/g/n
2 RJ-11 modem ports
Connectivity, optional:
Support the following external Jetdirect servers
Print only: HP Jetdirect en1700 External Print Server (J7988G), HP Jetdirect en3700 Fast-Ethernet External Print Server for Network Capable Hi-Speed USB 2.0 Peripherals (J7942G), HP Jetdirect ew2400 802.11b/g wireless and Fast Ethernet external print server (USB 2.0, 10/100Base-TX, 802.11b/g) (J7951G), HP Jetdirect ew2500 802.11b/g Wireless Print Server (J8021A)
Other supported accessories: Apple AirPort Express, Apple AirPort Extreme, Apple Airport Time Capsule
Minimum system requirements
Windows 10, 8.1, 8, 7: 32-bit or 64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer. Windows Vista: (32-bit only), 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer 8. Windows XP SP3 or higher (32-bit only): any Intel Pentium II, Celeron or 233 MHz compatible processor, 850 MB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer 8. Apple OS X v10.11 El Capitan, OS X v10.10 Yosemite, OS X v10.9 Mavericks
1 GB HD
Internet required
USB Linux (For more information, see http://hplipopensource.com/hplip-web/index.html)
Apple® OS X v10.11 El Capitan, OS X v10.10 Yosemite, OS X v10.9 Mavericks
1 GB HD
Internet required
USB
Compatible operating systems:
Windows 10, 8.1, 8, 7: 32-bit or 64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer. Windows Vista: (32-bit only), 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer 8. Windows XP SP3 or higher (32-bit only): any Intel Pentium II, Celeron or 233 MHz compatible processor, 850 MB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer 8. Apple OS X v10.11 El Capitan, OS X v10.10 Yosemite, OS X v10.9 Mavericks
1 GB HD
Internet required
USB Linux (For more information, see http://hplipopensource.com/hplip-web/index.html)
(Not supporting Windows XP (64-bit) andWindows Vista (64-bit))
[4] Wireless performance is dependent upon physical environment and distance from the access point. Wireless operations are compatible with 2.4 GHz routers only; excludes wireless direct. Wireless direct may require driver or apps be installed and connected on wireless-enabled mobile device or PC. Wireless functionality may vary by computer and mobile operating systems, see hpconnected.com. HP ePrint requires: account registration, HP ePrint-enabled printer, Internet connection, and a wireless-enabled mobile device or Internet-connected computer with email capability. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary. AirPrint supports OS X® Lion, OS X® Mountain Lion and the following devices running iOS 4.2 or later: iPad®, iPhone® (3GS or later), iPod touch® (3rd generation or later) and requires the printer be connected to the same network as your OS X or iOS device. AirPrint, the AirPrint Logo, iPad, iPhone, and iPod touch are trademarks of Apple® Inc. Windows is a trademark of the Microsoft group of companies. BlackBerry® names and logos are the property of Research In Motion Limited. Android is a trademark of Google Inc. |
| Web solutions & Services |
Web solutions:
HP JetAdvange On Demand
variety of Apps including Scan to email |
| Memory Spec |
Memory, standard: 512MB
Memory, maximum: 512 MB |
| Paper Handling |
Paper handling input, standard: 250-sheet input tray
Paper handling input, optional: Optional 250-sheet input tray
Paper handling output, standard: 150-sheet output tray
Maximum output capacity (sheets): Up to 150 sheets
Duplex printing: Automatic (standard)
Media sizes supported:
A4
A5
A6
B5 (JIS)
Envelope (DL, C5, C6, Chou #3, Chou #4)
Card (Hagaki, Ofuku Hagaki)
Media sizes, custom:
Tray 1: 76 x 127 to 216 x 356 mm
Media types:
Plain
HP EcoFFICIENT
HP Premium Presentation Matte 120g
HP Tri-fold Brochure Glossy 180g
HP Brochure Matte 180g
HP Brochure Glossy 180g
HP Advanced Photo Papers
Light 60-74g Intermediate 85-95g
Cardstock
Thick Plain Paper
Letterhead
Media weights, recommended: 60 to 105 g/m² (plain); 220 to 280 g/m² (photo); 75 to 90 g/m² (envelope); 163 to 200 g/m² (card)
Borderless printing: Yes, up to 8.5 x 11 in (US letter), 210 x 297 mm (A4) |
| Power & Operating Requirements |
Power:
Input voltage: 100 to 240 VAC (+/- 10%), 50/60 Hz
Power consumption:
35 watts maximum, 0.14 watts (Manual-Off), 7.20 watts (Standby), 1.30 watts (Sleep) 3
(Power measurements are based on ENERGY STAR® OM test procedure with 230 VAC, 50 Hz input.)
Energy efficiency: ENERGY STAR® certified
Operating temperature range: 5 to 40ºC |
| Dimensions |
Minimum
49.95 x 44.97 x 32.73 cm (desktop footprint)
49.95 x 53.01 x 32.73 cm (duplexer built-in, output tray no need to extend)
Maximum:
499.5 x 449.7 x 327.3 mm (desktop footprint)
499.5 x 530.1 x 327.3 mm (duplexer built-in, output tray no need to extend) |
| Weight |
Product: 15.2 kg
Package: 18.7 kg |
