MikroTik LtAP 4G kit a heavy-duty 4G (LTE) access point with GPS support
MikroTik LtAP 4G kit a heavy-duty 4G (LTE) access point with GPS support -
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Wireless Standard | 802.11b/g/n |
| Wireless Frequency | 2.4 GHz |
| Download Speed | 150 Mbps |
| Temperature Range | -40°C to +70°C |
| Ethernet Port | Gigabit |
Product details
Introducing LtAP 4G kit – a heavy-duty 4G (LTE) access point with GPS support.
The new LtAP 4G kit is a compact 4G (LTE) capable weatherproof wireless access point – perfect for busy urban environment or off-the-grid outdoors networking. It has a built-in cellular modem that supports 4G (LTE) connectivity – no need for additional devices, it works out of the box.
Its high power 2.4 GHz 802.11b/g/n wireless capability provides secure access to LTE network from your phone or any other wireless device with up to 150 Mbps download speed. You can also use a Gigabit Ethernet LAN port for your wired devices. There are several power options – DC jack, POE-in and automotive.
The rugged and extremely durable case with a special wall mounting kit will be perfect for almost any challenge: from public transportation, food trucks or logistics to harsh winter and stormy desert environment. LtAP can handle any temperature from -40 C° to +70 C°. It is a perfect solution for tracking vehicles in real time. We have provided a simple tracking application example in the RouterOS documentation to help you get started. LtAP even has 3 Mini-SIM slots for easy roaming management. Saves your time and money worldwide!
The unit comes with an extra miniPCIe slot, offering many expansion options. For example, you can install a second LTE modem for redundancy or a 5GHz interface to have dual concurrent 2.4 GHz / 5GHz AP + LTE. Another miniPCIe slot is already populated with the LTE modem.
LtAP has a RS232 serial port, which gives you console access for debugging, as well as full size USB for other devices.
RBLtAP-2HnD&R11e-4G includes LTE modem that supports International/USA bands 3, 7, 20, 31, 41n, 42 and 43.
The new LtAP 4G kit is more than an access point – it is what you need it to be wherever you need it to be.
SPECIFICATIONS
| Details | |
|---|---|
| Product code | RBLtAP-2HnD&R11e-4G |
| Architecture | MMIPS |
| CPU | MT7621A |
| CPU core count | 2 |
| CPU nominal frequency | 880 MHz |
| CPU Threads count | 4 |
| License level | 4 |
| Size of RAM | 128 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| Tested ambient temperature | -40°C to 70°C |
POWERING
| Details | |
|---|---|
| PoE in | Passive PoE |
| PoE in input Voltage | 12-30 V |
| Number of DC inputs | 3 (PoE-IN, Automotive, DC jack) |
| DC jack input Voltage | 12-30 V |
| Automotive input Voltage | 12-30 V |
| Max power consumption | 24 W |
| Max power consumption without attachments | 12 W |
MOBILE
| Details | |
|---|---|
| LTE Category | 4 (150Mbps Downlink, 50Mbps Uplink) |
| LTE FDD bands | 3 (1800MHz) / 7 (2600MHz) / 31 (450MHz) / 20 (800MHz) |
| LTE TDD bands | 42 (3500MHz) / 41n (2500MHz) / 43 (3700MHz) |
WIRELESS
| Details | |
|---|---|
| Wireless 2.4 GHz Max data rate | 300 Mbit/s |
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 2.5 |
| Wireless 2.4 GHz chip model | AR9382 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
ETHERNET
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 1 |
PERIPHERALS
| Details | |
|---|---|
| Number of SIM slots | 3 Modem (Mini SIM) |
| MiniPCI-e slots | 2 |
| Serial port | RS232 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 1 |
OTHER
| Details | |
|---|---|
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
CERTIFICATION & APPROVALS
| Details | |
|---|---|
| Certification | CE/RED, FCC, IC, E-MARK, EAC, ROHS |
WIRELESS SPECIFICATIONS
| 2.4 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 1MBit/s | 25 | -100 |
| 11MBit/s | 25 | -94 |
| 6MBit/s | 26 | -96 |
| 54MBit/s | 23 | -78 |
| MCS0 | 26 | -96 |
| MCS7 | 22 | -73 |
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Wireless Standard | 802.11b/g/n |
| Wireless Frequency | 2.4 GHz |
| Download Speed | 150 Mbps |
| Temperature Range | -40°C to +70°C |
| Ethernet Port | Gigabit |
| SIM Slots | 3 Mini-SIM |
| Serial Port | RS232 |
| Connectivity | 4G (LTE) |
