Omada TL-SG2428P JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+

Name: Omada TL-SG2428P JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+
Brand: TP-Link
SKU: PRD-202607-4467

JetStream™ 28-Port Gigabit Smart Switch with 24-Port PoE+ PORT: 24× Gigabit PoE+ Ports, 4× Gigabit SFP SlotsSPEC: 802.

Quote on request

✓ Available to order · supplied & installed in Malaysia

Request Quotation WhatsApp Ask a question

Genuine unit through the authorised channel — manufacturer warranty
Itemised quotation within 1 working day, B2B invoicing
Delivery nationwide — installation available for enterprise gear

Key specifications
Ports	24× Gigabit PoE+ Ports, 4× Gigabit SFP Slots
PoE Power Budget	250 W
Switching Capacity	56 Gbps
Packet Forwarding Rate	41.7 Mpps
Power Supply	100-240V AC, 50/60Hz

Full specifications ↓

Product details

JetStream™ 28-Port Gigabit Smart Switch with 24-Port PoE+

PORT: 24× Gigabit PoE+ Ports, 4× Gigabit SFP Slots

SPEC: 802.3at/af, 250 W PoE Power, 1U 19-inch Rack-mountable Steel Case

FEATURE: Integration with Omada SDN Controller, Static Routing, 802.1Q VLAN, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image, IPv6

HARDWARE FEATURES
Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Interface	• 24× 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) • 4× Gigabit SFP Slots
Network Media	• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) • 1000BASE-X: MMF, SMF
Fan Quantity	2
Power Supply	100-240V AC, 50/60Hz
PoE+ Ports(RJ45)	• Standard: 802.3at/af compliant • PoE+ Ports: 24 Ports • Power Supply: 250 W
PoE Ports (RJ45)	• Standard: 802.3at/af compliant • PoE+ Ports: 24 Ports • PoE Power Budget: 250 W*
Dimensions ( W x D x H )	17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm)
Mounting	Rack Mountable
Max Power Consumption	• 32.1 W (110 V/ 60 Hz with no PD connected) • 308.6 W (110 V/ 60 Hz with 250 W PD connected)
Max Heat Dissipation	109.53 BTU/h (with no PD connected) • 1052.94 BTU/h (with 250 W PD connected)

PERFORMANCE
Switching Capacity	56 Gbps
Bandwidth/Backplane	56 Gbps
Packet Forwarding Rate	41.7 Mpps
MAC Address Table	8K
Packet Buffer Memory	4.1 Mbit
Jumbo Frame	9KB

SOFTWARE FEATURES
Quality of Service	• Support 802.1p CoS/DSCP priority • Support 8 priority queues • Queue scheduling: SP, WRR, SP+WRR • Port/Flow- based Rate Limiting • IPv6 QoS • Voice VLAN
L2 and L2+ Features	• Static Routing • DHCP Relay • DHCP Server • IGMP Snooping V1/V2/V3 • 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group) • Spanning Tree STP/RSTP/MSTP • BPDU Filtering/Guard • TC/Root Protect • Loopback detection • 802.3x Flow Control • LLDP, LLDP-MED
VLAN	• Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs) • MAC/Protocol-based VLAN
Access Control List	• L2–L4 package filtering • MAC ACL • IP ACL • Combined ACL • IPv6 ACL
Security	• AAA • Port Security • DHCP Snooping • IP-MAC-Port Binding • IPv6-MAC-Port Binding • ARP Inspection • 802.1x and Radius Authentication • SSH v1/v2 • SSL v3/TLSv1.2 • Broadcast/Multicast/Unknown-unicast Storm Control • Dos Defend
IPv6	• Dual IPv4/IPv6 stack • Multicast Listener Discovery (MLD) Snooping • IPv6 neighbor discovery (ND) • Path maximum transmission unit (MTU) discovery • Internet Control Message Protocol (ICMP) version 6 • TCPv6/UDPv6
IPv6 Applications	• DHCPv6 Client • Ping6 • Tracert6 • Telnet (v6) • IPv6 SNMP • IPv6 SSH • IPv6 SSL • Http/Https • IPv6 TFTP
Advanced Features	• Automatic Device Discovery • Batch Configuration • Batch Firmware Upgrading • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule
MIBs	• MIB II (RFC1213) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC2618) • Remote Ping, Traceroute MIB (RFC2925) • Support TP-Link private MIBs • RMON MIB(RFC1757, rmon 1,2,3,9)

MANAGEMENT
Omada App	Yes
Centralized Management	• Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller
Cloud Access	Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller (Supported by TL-SG2428P v1, v3 and above, while is not supported by TL-SG2428P v2)
Management Features	• Web-based GUI and CLI management • SNMP v1/v2c/v3,compatible with public MIBs and TP-Link private MIBs • RMON (1, 2, 3, 9 groups) • CPU Monitoring • Port Mirroring • Firmware Upgrade: TFTP & Web • System Diagnose: VCT • SYSLOG & Public MIBS • Dual Image • EEE

OTHERS
Certification	CE, FCC, RoHS
Package Contents	TL-SG2428P • Power Cord • Installation Guide • Rackmount Kit • Rubber Feet
System Requirements	Microsoft® Windows® XP, Vista™ or Windows 7, Windows 8, Windows 10, MAC® OS, NetWare®, UNIX® or Linux.
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
