QNAP TS-932PX-4G 9-Bay NAS Enclosure
QNAP TS-932PX-4G 9-Bay NAS Enclosure - Key Features5 x 3.
Quote on request
✓ Available to order · supplied & installed in Malaysia
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Drive bays | 9 |
Product details
Key Features
- 5 x 3.5" / 4 x 2.5" SATA Drive Bays
- 1.7 GHz ARM Cortex-A57 CPU
- 4GB DDR4 RAM
- 2 x 2.5GbE RJ45 Ports
- 2 x 10GbE SFP+ Ports
- 3 x USB 3.2 Gen 1 Ports
- RAID 0, 1, 5, 6, 10, 50, and 60
- QTS Operating System
TS-932PX-4G
| CPU | AnnapurnaLabs Alpine AL324 ARM® Cortex-A57 4-core 1.7GHz processor |
| CPU Architecture | 64-bit ARM |
| Floating Point Unit | |
| Encryption Engine | |
| System Memory | 4 GB SODIMM DDR4 (1 x 4 GB) |
| Maximum Memory | 16 GB (1 x 16 GB) |
| Memory Slot | 1 x SODIMM DDR4 |
| Flash Memory | 512 MB (Dual boot OS protection) |
| Drive Bay | 5x 3.5-inch+ 4 x 2.5-inch SATA 6Gb/s |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch solid state drives |
| Hot-swappable | |
| SSD Cache Acceleration Support | |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M/10M) |
| 10 Gigabit Ethernet Port | 2 x 10GbE SFP+ |
| Wake on LAN (WOL) | Only the 2.5GbE port |
| Jumbo Frame | |
| USB 3.2 Gen 1 port | 3 |
| Form Factor | Tower |
| LED Indicators | System Status, LAN, USB, HDD1~5, SSD1-4 |
| Buttons | Power, Reset, USB Copy |
| Dimensions (HxWxD) | 176.5 × 224.6 × 224.1 mm Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
| Weight (Net) | 4.66 kg |
| Weight (Gross) | 5.2 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | External, 120 W, AC 100 to 240 V |
| Power Consumption: HDD Sleep Mode | 23.833 W |
| Power Consumption: Operating Mode, Typical | 43.003 W Tested with drives fully populated. |
Supplied & supported by PrinterBullet
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Synology backup & 3-2-1 architecture →
Need help choosing?
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| NAS Specs | |
|---|---|
| Drive bays | 9 |
