Ruijie Reyee RG-NBS5200-24GT4XS-P 24-port Gigabit Layer 2+ PoE Switch
Buy Ruijie Reyee RG-NBS5200-24GT4XS-P 24-port Gigabit Layer 2+ PoE Switch, Ruijie from Printer Bullet - Everything for office. Fast & Free Home Delivery. High Q...
Quote on request
✓ Available to order · supplied & installed in Malaysia
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ports | 24 x 10/100/1000Base-T PoE+ ports, 4 SFP+ uplink |
| Switching Capacity | 128 Gbps |
| MAC Address Table | 16000 |
| Dimensions | 440 mm x 350 mm x 43.6 mm |
| PoE Power | 370W |
Product details
- 24-Port gigabit Layer 3 managed PoE switch, 4 SFP+ uplink
- Enterprise-class Quality Ensures High Performance
- 6KV surge protection reduces the possibility of port damage
- Multiple Security Policies Protect Your Network
- Lifetime management on Ruijie Cloud at anytime anywhere
Key Specification
Ports
24 x 10/100/1000Base-T PoE+ ports, 4 SFP+ uplink
Switching capacity
128 Gbps
MAC address table
16000
Fan
Dual, Left/Right-to-Rear
Dimensions (W x D x H)
440 mm x 350 mm x 43.6 mm
MTBF
> 200,000
PoE(802.3af)/PoE+(802.3at)
370W
Forwarding rate
96 Mbps
Maximum VLAN
4094
Port surge
6 kV
Weight (With package)
4.5 kg
Warranty
5 Years
Supplied & supported by PrinterBullet
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Need help choosing?
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Ports | 24 x 10/100/1000Base-T PoE+ ports, 4 SFP+ uplink |
| Switching Capacity | 128 Gbps |
| MAC Address Table | 16000 |
| Dimensions | 440 mm x 350 mm x 43.6 mm |
| PoE Power | 370W |
| Forwarding Rate | 96 Mbps |
| Maximum VLAN | 4094 |
| Port surge protection | 6 kV |
