RUIJIE RG-S1920-18GT2SFP SMART MANAGED SWITCH, 18 GE PORT, 2 GE SFP (NON COMBO)

Product details

XS-S1920 Switch Series

Ruijie XS-S1920-E/RG-S1920 Series Switches are the next-generation cost-effective smart managed Layer 2 switches for commercial real estate, hotels and CCTV. The series is designed for small and medium-sized businesses looking for easy-to-deploy solution.

Ruijie S1920 Series is part of the Ruijie SME networking products. The series consists of 7 switches including one 8-port Gigabit PoE+ models, one 16-port Gigabit model, one 24-port Gigabit model, two 24-port Fast Ethernet PoE+ models, and two 24-port Gigabit PoE+ switch models.

These switches can be deployed with plug-and-play out the box. Also they can be fine-tuned with features available from built-in Web-UI as well as command lines(CLI). Features including VLAN, Spanning Tree, IGMP Snooping can be configured.

With Ruijie Cloud, fast deployment, centralized monitoring and remote maintenance can be done in more efficient ways. Using Smart+ features for CCTV, configurations for IP cameras can be done automatically on PoE models, lots of man power and time saved on site.



Key Features

● Efficient management using Ruijie Cloud, Web-UI and command lines

● 24-port 10/100, 8-, 16- and 24-port Gigabit models with GT and SFP ports for uplink

● All 8/24 ports are PoE/PoE+ capable on PoE models

● Extra surge protection of 8KV on PoE models and 10KV on non-PoE models

● Wide operating temperature from -5℃ to 55℃

● Unique Smart+ features including Auto Smart Deployment and Remote Reboot Helper guarantee the experience on CCTV networks



Specification

Ports

10/100/1000BASE-T > 18

1000M SFP: 2

Packet Buffer: 4.1Mbit

CPU Memory: 256MB

Flash: 32MB

Dimensions(WxDxH): 440x189x43.6mm

Surge Protection: 10KV

Unit Weight: 2.4Kg

Frequency: 50/60Hz

AC Voltage: 100~240V

Maximum Power Rating: 17W

RoHS: Yes

EEE: Yes

Operating Temperature: -5 ℃ ~ 55 ℃

Storage Temperature: -40 ℃ ~ 70 ℃

Warranty: 3-Year Warranty Free of Charge
