RUIJIE XG-SFP-LR-SM1310 ENT SFP TRANSCEIVER 10G BASE-LR, SM (1310nm, 10km, LC PORT)
The XG-SFP-LR-SM1310 is an optical module.
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Wavelength | 1310nm |
| DDM | Yes |
| Optical Fiber Type | SMF |
| Connector Type | LC |
| Core Specification | 9/125um |
Product details
The XG-SFP-LR-SM1310 is an optical module. The 10G SFP+ transceiver is an input/output device that supports hot swapping. When connected to a 10G SFP+ Ethernet port or slot through the optical fiber, the 10G SFP+ transceiver implements 10G Ethernet transmission
Specification
Waveleng th (nm) : 1310
DDM: Yes
Optical Fiber Type: SMF
Intensity of Transmitted Light/dBm: Min -8.2, Max 0.5
Intensity of Received Light/dBm: Min -14.4, Max 0.5
Cabling Specification
Connect or Type: LC
Optical Fiber Type: SMF
Core Specification (um): 9/125
Modal Bandwidth (MHz.km): N/A
Maximum Cabling Distance: 10KM
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Wavelength | 1310nm |
| DDM | Yes |
| Optical Fiber Type | SMF |
| Connector Type | LC |
| Core Specification | 9/125um |
| Maximum Cabling Distance | 10km |
| Transmitted Light Intensity | Min -8.2, Max 0.5 dBm |
| Received Light Intensity | Min -14.4, Max 0.5 dBm |
