Synology RackStation RS1221+ 8-Bay 3.5" SATA HDD NAS

Name: Synology RackStation RS1221+ 8-Bay 3.5" SATA HDD NAS
Brand: Synology
SKU: PRD-202607-5247

Buy Synology RackStation RS1221+ 8-Bay 3.5" SATA HDD NAS, Synology from Printer Bullet - Everything for office. Fast & Free Home Delivery. High Quality Service

Quote on request

✓ Available to order · supplied & installed in Malaysia

Request Quotation WhatsApp Ask a question

Genuine unit through the authorised channel — manufacturer warranty
Itemised quotation within 1 working day, B2B invoicing
Delivery nationwide — installation available for enterprise gear

Key specifications
Form factor	Rackmount

Full specifications ↓

Product details

Key Features 8 x 3.5"/2.5" SATA Drive Bays 2.2 GHz AMD Ryzen V1500B Quad-Core 4GB of DDR4 ECC RAM (1 x 4GB, Max 32GB) 4 x Gigabit Ethernet Ports 2 x USB 3.0 Type-A \| 1 x eSATA 1 x PCIe Gen 3.0 x8 Slot (x4 Link) RAID 0, 1, 5, 6, 10, and JBOD AES-NI Hardware Encryption Engine 250W Power Supply Synology DiskStation Manager OS (DSM) CPU
CPU Model	AMD Ryzen V1500B
CPU Quantity	1
CPU Architecture	64-bit
CPU Frequency	4-core 2.2 GHz
Hardware Encryption Engine (AES-NI)
Memory
System Memory	4 GB DDR4 ECC SODIMM
Memory Module Pre-installed	4 GB (4 GB x 1)
Total Memory Slots	2
Maximum Memory Capacity	32 GB (16 GB x 2)
Notes	Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion. For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.
Storage
Drive Bays	8
Maximum Drive Bays with Expansion Unit	12 (RX418 x 1)
Compatible Drive Type* (See all supported drives)	3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD
Hot Swappable Drive*
Notes	"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port	4 (with Link Aggregation / Failover support)
USB 3.2 Gen 1 Port*	2
eSATA Port	1
Notes	The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe
PCIe Expansion	1 x Gen3 x8 slot (x4 link)
File System
Internal Drives	Btrfs EXT4
External Drives	Btrfs EXT4 EXT3 FAT NTFS HFS+ exFAT
Notes	exFAT Access can be installed for free from Package Center in DSM 7.0. In DSM 6.2 or earlier versions, exFAT Access needs to be purchased in Package Center.
Appearance
Form Factor (RU)	2U
Size (Height x Width x Depth)	RS1221+ :88 mm x 482 mm x 306.6 mmRS1221RP+ :88 mm x 482 mm x 407.5 mm
Weight	RS1221+ :6.9 kgRS1221RP+ :11.7 kg
Rack Installation Support*	RS1221+ : 4-post 19" rack (Synology Rail Kit - RKM114/RKS-02) 2-post 19" rack (direct mounting) RS1221RP+ :4-post 19" rack (Synology Rail Kit - RKS-02)
Notes	The rail kit is sold separately
Others
System Fan	80 mm x 80 mm x 2 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode
Power Recovery
Noise Level*	RS1221+ :25.2 dB(A)RS1221RP+ :40 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter	RS1221+ :250 WRS1221RP+ :350 W
Redundant Power Supply	RS1221+ :-RS1221RP+ :
AC Input Power Voltage	100 V to 240 V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption	RS1221+ :49.89 W (Access) 22.64 W (HDD Hibernation) RS1221RP+ :61.94 W (Access) 29.98 W (HDD Hibernation)
British Thermal Unit	RS1221+ :170.23 BTU/hr (Access) 77.25 BTU/hr (HDD Hibernation) RS1221RP+ :211.35 BTU/hr (Access) 102.30 BTU/hr (HDD Hibernation)
Notes	Power consumption is measured when it is fully loaded with Western Digital 1TB WD10EFRX hard drive(s). Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
Operating Temperature	0°C to 35°C (32°F to 95°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Relative Humidity	5% to 95% RH
Certification
FCC CE BSMI EAC CCC KC VCCI RCM
Warranty
3-year hardware warranty, extendable to 5 years with Extended Warranty Plus
Notes	Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions. The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
Environment
RoHS Compliant
Packaging Content
RS1221+ : Main Unit X 1 Accessory Pack X 1 AC Power Cord X 1 C13 to C14 power cord x 1 Quick Installation Guide X 1 RS1221RP+ : Main Unit X 1 Accessory Pack X 1 AC Power Cord X 2 Quick Installation Guide X 1
Optional Accessories
RS1221+ : DDR4 ECC SODIMM: D4ES01-4G/D4ES01-8G/D4ECSO-2666-16G Expansion Units: RX418 3.5" SATA HDD: HAT5300 2.5" SATA SSD: SAT5210 M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1 M.2 SSD Adapter Card: M2D20 25GbE Network Interface Card: E25G21-F2 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1 Rail Kit Sliding: RKS-02 Rail Kit Mounted: RKM114* VisualStation: VS360HD Surveillance Device License Pack RS1221RP+ : DDR4 ECC SODIMM: D4ES01-4G/D4ES01-8G/D4ECSO-2666-16G Expansion Units: RX418 3.5" SATA HDD: HAT5300 2.5" SATA SSD: SAT5210 M.2 SSD & 10GbE Combo Adapter Card: E10M20-T1 M.2 SSD Adapter Card: M2D20 25GbE Network Interface Card: E25G21-F2 10GbE Network Interface Card: E10G21-F2/E10G18-T2/E10G18-T1 Rail Kit Sliding: RKS-02 VisualStation: VS360HD Surveillance Device License Pack
Notes	RS1221+ : Certa
