TP-Link 10-Port 10/100Mbps Desktop Switch with 8-Port PoE+ (LS110P)
10-port Fast Ethernet desktop switch with 8 PoE+ ports, ideal for small offices needing simple wired connectivity.
- 8 PoE+ ports to power cameras and access points
- Plug-and-play setup with no configuration needed
- Compact desktop form factor saves desk space
- Supports 10/100Mbps speeds across all ports
- Fanless design for quiet office environments
MYR 229.00
— buy online, or request a project quotation
✓ Available to order · supplied & installed in Malaysia
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Standards and Protocols | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| Interface | 10*10/100 Mbps RJ45 Ports with 8 PoE+ Ports (Port 1 to Port 8); AUTO Negotiation/AUTO MDI/MDIX |
| External Power Supply | External Power Adapter (Power Input: 220~240V, 50/60Hz (NV), Output: 53.5 VDC / 1.92 A) |
| Packet Forwarding Rate | 1.488 Mpps |
| PoE Ports (RJ45) | Standard: 802.3 af/at compliantPoE Ports: Port 1- Port 8Power Supply: 96 W |
Product details
The LS110P simplifies network expansion by combining data and power delivery over standard Ethernet cables. With 8 PoE+ ports rated at 30W each and a 96W total power budget, it handles multiple powered devices from a single connection point. Built for plug-and-play installation, this fanless switch requires no configuration and operates silently—a practical fit for offices, retail spaces, and surveillance installations. TP-Link engineered this switch with business reliability in mind. Isolation Mode separates client traffic for enhanced security, while PoE Auto Recovery automatically reboots unresponsive devices to maintain uptime. The Extend Mode pushes data and power transmission to 250m (820ft), supporting extended deployments beyond standard cable limits. - 10 × 10/100 Mbps RJ45 ports (8 PoE+, 2 non-PoE) - 30W per-port PoE+ output; 96W total PoE budget - 250m extended transmission range (Extend Mode) - Isolation Mode for traffic separation and security - PoE Auto Recovery for automatic PD device reboot - Fanless design with silent operation - Desktop or wall-mount form factor - IEEE 802.3af/at/x compliant - Plug-and-play, zero-configuration setupSupplied & supported by PrinterBullet
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Need help choosing?
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Switch Specs | |
|---|---|
| Standards and Protocols | IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| Interface | 10*10/100 Mbps RJ45 Ports with 8 PoE+ Ports (Port 1 to Port 8); AUTO Negotiation/AUTO MDI/MDIX |
| External Power Supply | External Power Adapter (Power Input: 220~240V, 50/60Hz (NV), Output: 53.5 VDC / 1.92 A) |
| Packet Forwarding Rate | 1.488 Mpps |
| PoE Ports (RJ45) | Standard: 802.3 af/at compliantPoE Ports: Port 1- Port 8Power Supply: 96 W |
| Dimensions ( W x D x H ) | 6.7×3.9×1.1 in (171×98×27 mm) |
| Switching Capacity | 2 Gbps |
| Transmission Method | Store-And-Forward |
| General | |
|---|---|
| Brand | TP-Link |
| Model | LS110P |
| Connectivity | |
|---|---|
| Total Ports | 10 |
| Port Speed | 10/100 |
| PoE+ Ports | 8 |
| PoE Standard | IEEE 802.3at/af |
| Physical | |
|---|---|
| Form Factor | Desktop |
| Cooling | Fanless |
Compare similar
Related products
Your research
You recently viewed
Frequently asked questions
How much does the TP-Link 10-Port 10/100Mbps Desktop Switch with 8-Port PoE+ (LS110P) cost?
The reference price is MYR 229.00. Contact us for a formal quotation — project pricing depends on quantity and installation scope.
Is this product available in Malaysia?
Yes — available to order. Supplied and installed nationwide by RYZEN ESOLUTIONS (M) SDN. BHD..
Who manufactures the TP-Link 10-Port 10/100Mbps Desktop Switch with 8-Port PoE+ (LS110P)?
It is manufactured by TP-Link. We supply genuine units with manufacturer warranty.
Do you provide installation and support?
Yes — we design, install, configure and support this product as part of a complete solution. Ask us about maintenance packages.
