TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE+ (TL-SF1005P)
TP-Link 5-port Fast Ethernet desktop switch with 4 PoE+ ports, ideal for small offices needing simple wired connectivity.
- 4 PoE+ ports to power cameras, phones and APs
- Plug-and-play setup with no configuration needed
- Compact desktop form factor saves desk space
- IEEE 802.3at/af PoE+ standard supported
- Fanless design for quiet office environments
MYR 139.00
— buy online, or request a project quotation
✓ Available to order · supplied & installed in Malaysia
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Interface | 5× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af/at PoE+ ports); AUTO Negotiation; AUTO MDI/MDIX |
| External Power Supply | External Power Adapter (Output: 53.5 V DC / 1.31 A) |
| Packet Forwarding Rate | 0.744 Mpps |
| PoE Ports (RJ45) | Standard: 802.3 af/at compliant; PoE Ports: Ports 1–4; Power Supply: 67 W |
| Switching Capacity | 1 Gbps |
Product details
This unmanaged switch combines five 10/100Mbps Ethernet ports with four dedicated PoE+ ports, eliminating the need for separate power infrastructure. Four of the five ports support IEEE 802.3af/at PoE+ delivery at up to 30W per port (67W total), enabling you to power and connect IP cameras, access points, and other PoE-compliant devices across distances up to 250m in Extend Mode. With plug-and-play deployment and no configuration required, the TL-SF1005P suits small businesses, office surveillance, and distributed network applications. Its Priority Mode intelligently allocates bandwidth to ports 1-2, ensuring quality service for critical applications. The durable metal casing and intelligent power management provide reliability in compact desktop environments. - 5× 10/100 Mbps RJ45 ports - 4× PoE+ ports (IEEE 802.3af/at compliant) - 30W maximum per PoE port - 67W total PoE power budget - Up to 250m data and power transmission (Extend Mode) - One-click Priority Mode for ports 1-2 - Plug and play, no configuration needed - Durable metal casing - Compatible with IP cameras, access points, IP phones, and other PoE devicesSupplied & supported by PrinterBullet
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Need help choosing?
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Switch Specs | |
|---|---|
| Interface | 5× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af/at PoE+ ports); AUTO Negotiation; AUTO MDI/MDIX |
| External Power Supply | External Power Adapter (Output: 53.5 V DC / 1.31 A) |
| Packet Forwarding Rate | 0.744 Mpps |
| PoE Ports (RJ45) | Standard: 802.3 af/at compliant; PoE Ports: Ports 1–4; Power Supply: 67 W |
| Switching Capacity | 1 Gbps |
| Dimensions ( W x D x H ) | 3.9 x 3.9 x 1.0 in (99.8 x 98 x 25 mm) |
| Transmission Method | Store-And-Forward |
| General | |
|---|---|
| Brand | TP-Link |
| Model | TL-SF1005P |
| Total Ports | 5 |
| Port Speed | 10/100 |
| PoE+ Ports | 4 |
| Total PoE Budget | 65 W |
| PoE Standard | IEEE 802.3at/af |
| Switching | Unmanaged |
| Physical | |
|---|---|
| Mounting | Desktop |
| Fan | Fanless |
Compare similar
Related products
Your research
You recently viewed
Frequently asked questions
How much does the TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE+ (TL-SF1005P) cost?
The reference price is MYR 139.00. Contact us for a formal quotation — project pricing depends on quantity and installation scope.
Is this product available in Malaysia?
Yes — available to order. Supplied and installed nationwide by RYZEN ESOLUTIONS (M) SDN. BHD..
Who manufactures the TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE+ (TL-SF1005P)?
It is manufactured by TP-Link. We supply genuine units with manufacturer warranty.
Do you provide installation and support?
Yes — we design, install, configure and support this product as part of a complete solution. Ask us about maintenance packages.
