TP-Link 5-Port Gigabit Desktop PoE+ Switch with 1-Port PoE++ In and 4-Port PoE+Out (TL-SG1005P-PD)
A compact 5-port Gigabit PoE+ desktop switch that draws power via PoE++ and passes it downstream — ideal for clutter-free network installations.
- Powered by PoE++ uplink — no separate power adapter needed
- 4 downstream PoE+ ports to power IP cameras and APs
- Full Gigabit speeds on all five ports
- Compact desktop form factor saves rack space
- Plug-and-play setup with no configuration required
MYR 229.00
— buy online, or request a project quotation
✓ Available to order · supplied & installed in Malaysia
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x, IEEE 802.1p |
| Power Supply | Only Powered by PoE Device |
| Dimensions ( W x D x H ) | 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) |
| Model | TL-SG1005P-PD |
| Total Ports | 5 |
Product details
The TL-SG1005P-PD is a desktop PoE+ switch engineered for locations where power infrastructure is limited. It accepts a single PoE++ input and distributes power and connectivity across four PoE+ output ports plus one standard data port, supporting budgets up to 66W (802.3bt Type 4) down to 9W (802.3af). The fanless metal chassis operates silently and mounts on desktops or walls, making it suitable for office, retail, and outdoor surveillance environments. Simplified deployment is a key strength: plug in upstream PoE power, connect your devices, and it works immediately—no CLI or web interface required. Long-Range PoE+ mode extends transmission to 250 meters, perfect for large-area camera coverage. Built-in PoE Auto Recovery automatically reboots unresponsive powered devices to maintain uptime without manual intervention. - 5× Gigabit RJ45 ports (10/100/1000 Mbps) - 1-port PoE++ input, 4-port PoE+ output - Up to 66W PoE budget (802.3bt Type 4); 47W Type 3; 21W 802.3at; 9W 802.3af - Long-Range PoE+ mode: 250m transmission distance - PoE Auto Recovery for automatic device reboot - Fanless design with metal casing - Desktop and wall-mount options - Plug-and-play operation; no configuration required - PoE power supply only (no AC/DC input)Supplied & supported by PrinterBullet
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Need help choosing?
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Switch Specs | |
|---|---|
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x, IEEE 802.1p |
| Power Supply | Only Powered by PoE Device |
| Dimensions ( W x D x H ) | 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) |
| General | |
|---|---|
| Model | TL-SG1005P-PD |
| Total Ports | 5 |
| Port Speed | 10/100/1000 Mbps (Gigabit) |
| PoE++ Input Port | 1 × IEEE 802.3bt (Port 5) |
| PoE+ Output Ports | 4 × IEEE 802.3af/at |
| Switching | Unmanaged |
| Physical | |
|---|---|
| Form Factor | Desktop |
