APC BX800LI-MS UPS (800VA, 230V, AVR)

APC Back-UPS BX800LI-MS 800VA AVR UPS providing battery backup and surge protection for home and small office equipment.

800VA/400W capacity for PCs and networking gear
Automatic Voltage Regulation stabilises fluctuating power
Battery backup keeps equipment running during outages
Surge and spike protection safeguards connected devices
LED status indicators for easy at-a-glance monitoring

MYR 479.00 — buy online, or request a project quotation

✓ Available to order · supplied & installed in Malaysia

Request Quotation WhatsApp Ask a question

Genuine unit through the authorised channel — manufacturer warranty
Itemised quotation within 1 working day, B2B invoicing
Delivery nationwide — installation available for enterprise gear

Key specifications
Type	UPS
Capacity	800 VA
Real power	415 W
Topology	Line-interactive
Form	Tower

Full specifications ↓

Product details

APC BX800LI-MS UPS

800VA | 230V | AVR

Warranty
- 2 year Manufacturer Limited Warranty (APC Service Center)

SPECIFICATIONS

Specifications
Model	BX800LI-MS
Output	Output power capacity: 415 Watts / 800 VA Max Configurable Power (Watts): 415 Watts / 800 VA Nominal Output Voltage: 230V Output Frequency (sync to mains): 50/60 Hz +/-1 Hz Output Frequency (not synced): 50/60 Hz +/-1 Hz Topology: Line Interactive Waveform type: Stepped approximation to a sinewave Output Connections: (1) IEC 320 C13 (Battery Backup) Transfer Time: 4ms typical : 6ms maximum
Input	Nominal Input Voltage: 230V Input frequency: 50/60 Hz +/- 3 Hz (auto sensing) Input Connections: IEC-320 C14, NEMA 5-15P Cord Length: 1.22 meters Input voltage range for main operations: 140 - 300 V Number of Power Cords: 1 Type of Input Protection Required: 3-pole breaker Maximum Input Current: 7.0 A Input Power Factor at Full Load: 0.52
Batteries & Runtime	Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof Included Battery Modules: 1 Typical recharge time: 6 hour(s) Replacement Battery: APCRBC110 Battery Volt-Amp-Hour Capacity: 81
Communications & Management	Control panel: LED status display with load and battery bar-graphs and On Line : On Battery : Replace Battery : and Overload Indicators Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering	Surge energy rating: 273 Joules
Physical	Maximum Height: 200 mm , 20.0 CM Maximum Width: 115 mm , 11.5 CM Maximum Depth: 256 mm , 25.6 CM Net Weight: 6.5 KG Shipping weight: 6.7 KG Shipping Height: 290 mm , 29.0 CM Shipping Width: 205 mm , 20.5 CM Shipping Depth: 345 mm , 34.5 CM
Environmental	Operating Environment: 0 - 40 °C Operating Relative Humidity: 0 - 95 % Operating Elevation: 0-3000 meters Storage Temperature: -15 - 40 °C Storage Relative Humidity: 0 - 95 % Storage Elevation: 0-9000 meters Audible noise at 1 meter from surface of unit: 45.0 dBA
Conformance	Approvals: CE, WEEE Standard warranty: 2 years repair or replace
Sustainable Offer Status	RoHS: Compliant REACH: Contains No SVHCs
* Prices, Features, Package Content and Specifications are subject to change without prior notification.*

Supplied & supported by PrinterBullet

Delivery & professional installation
Configuration & commissioning
Manufacturer warranty handling
Annual maintenance & managed services (MSP)

Engineering by our services division, Ryzen ESolutions — Power protection & high availability →

Need help choosing?

Talk to the engineers who install this equipment — free sizing advice, no obligation.

012-282 2340 WhatsApp Request Quotation

Specifications

Storage Media Specs
Type	UPS

UPS Specs
Capacity	800 VA
Real power	415 W
Topology	Line-interactive
Form	Tower
Network card slot	No
Battery replaceable	Yes

General
Brand	APC
Model	BX800LI-MS

Power
Capacity (VA)	800 VA
Capacity (Watts)	400 W
Input Voltage	230 V
Automatic Voltage Regulation (AVR)	Yes
Waveform Type	Stepped Approximation to Sine Wave

Physical
Form Factor	Tower
