Ubiquiti Rocket 5AC airMAX® ac BaseStation (R5AC‑Lite)
Buy Ubiquiti Rocket 5AC airMAX® ac BaseStation (R5AC‑Lite), Ubiquiti from Printer Bullet - Everything for office. Fast & Free Home Delivery. High Quality Servic...
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Frequency Band | 5 GHz |
| Interface | 1x 10/100/1000 Ethernet Port |
| Dimensions | 162 x 84 x 37 mm |
| Weight | 250 g |
| Max. Power Consumption | 8.5W |
Product details
- PtP backhaul Rocket5ac Lite with the RocketDish™ ac
- PtMP links Rocket5ac Lite with the airMAX ac Sector
- 5 GHz Frequency Band
- Gigabit Ethernet
- Passive Power over Ethernet (PoE)
- Output Power
- Plug and Play Integration
Ubiquiti has designed the first airMAX® ac radios for high performance and ease of installation. You have the freedom to deploy the Rocket® ac anywhere in the world, and it allows for a high degree of flexibility in configuring channel bandwidths (subject to local country regulations). Pair the Rocket5ac Lite with airMAX ac antennas for optimal performance:
Features:
| R5AC-LITE | |
|---|---|
| Dimensions | 162 x 84 x 37 mm (6.4 x 3.3 x 1.5") |
| Weight | 250 g (8.82 oz) |
| Networking Interface | (1) 10/100/1000 Ethernet Port |
| RF Connectors | (2) RP-SMA (Waterproof) |
| LEDs | Power, LAN, (4) Signal Strength |
| Enclosure | Outdoor UV Stabilized Plastic |
| Max. Power Consumption | 8.5W |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Power Method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Operating Temperature | -40 to 80° C (-40 to 176° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| ESD/EMP Protection | ± 24kV Contact / Air for Ethernet |
| Shock and Vibration | ETSI300-019-1.4 |
| Certifications | CE, FCC, IC |
| Worldwide | 5150 – 5875 |
| US/CA U-NII-1 U-NII-2A U-NII-2C U-NII-3 | 5150 - 5250 5250 - 5350 5470 - 5725 5725 - 5850 |
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Frequency Band | 5 GHz |
| Interface | 1x 10/100/1000 Ethernet Port |
| Dimensions | 162 x 84 x 37 mm |
| Weight | 250 g |
| Max. Power Consumption | 8.5W |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter |
| Operating Temperature | -40 to 80° C |
| Enclosure | Outdoor UV Stabilized Plastic |
