Ubiquiti USW-24 layer 2 switch with (24) GbE RJ45 ports and (2) 1G SFP ports
Ubiquiti USW-24 layer 2 switch with (24) GbE RJ45 ports and (2) 1G SFP ports -
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ethernet Ports | 24 GbE RJ45 |
| SFP Ports | 2 x 1G SFP |
| Switching Capacity | 52 Gbps |
| Throughput | 26 Gbps |
| Power Consumption | 25W |
Product details
The Switch 24 (USW 24) is a fully managed, fanless switch with (24) GbE RJ45 ports and (2) 1G SFP ports. The versatile USW 24 provides Gigabit links to Ethernet devices while also supplying Gigabit fiber uplink options fit for an enterprise network. The switch also offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate), and features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can also be monitored or configured from anywhere with the powerful, intuitive Network web application and mobile app.
- (24) GbE RJ45 ports
- (2) 1G SFP ports
- (1) 1.3" LCM color touchscreen with AR switch management
- Fanless, silent cooling
Features:
Managed with the UAP Network application: Version 5.12.32 and later
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 200 x 43.7 mm (17.42 x 7.87 x 1.72") |
| Weight | Without Mount: 2.70 kg (5.95 lb) With Mount: 2.79 kg (6.15 lb) |
| Enclosure Material | SGCC Steel |
| Hardware | |
| Total Non-Blocking Throughput | 26 Gbps |
| Switching Capacity | 52 Gbps |
| Forwarding Rate | 38.69 Mpps |
| Max. Power Consumption | 25W |
| Power Method | Universal AC Input: 100-240VAC, 50/60 Hz |
| Power Supply | AC/DC, Internal, 36W |
| Networking Interfaces | (24) 10/100/1000 Mbps Ethernet RJ45 Ports (2) 1 Gbps SFP Ports |
| Management Interface | Ethernet In-Band |
| Modes | SMB Layer 2 Gigabit Ethernet Switch |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | (1) Bootup Animation: Bootup in Progress Firmware Upgrade Icon: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted |
| Ethernet | Green: 1G, Amber: 10/100 Mbps |
| SFP | Green: 1G |
- Delivery & professional installation
- Configuration & migration
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Ethernet Ports | 24 GbE RJ45 |
| SFP Ports | 2 x 1G SFP |
| Switching Capacity | 52 Gbps |
| Throughput | 26 Gbps |
| Power Consumption | 25W |
| Operating Temperature | -5 to 40°C |
| Dimensions | 442.4 x 200 x 43.7 mm |
| Weight | 2.70 kg |
