APC · UPS

APC Back-UPS 500, 230V (BK500EI)

Name: APC Back-UPS 500, 230V (BK500EI)
Brand: APC
SKU: PRD-202607-0048
Price: 857 MYR
Availability: PreOrder

APC Back-UPS 500, 230V (BK500EI) - APC Back-UPS 500, 230V (BK500EI) 300 Watts, 500 VA | Input & Output voltage 230V Warranty - 2 years Manufactorer Limited Wa...

MYR 857.00 reference price — project pricing on quotation

✓ Available to order · supplied & installed in Malaysia

Request Quotation WhatsApp Ask a question

Genuine unit through the authorised channel — manufacturer warranty
Itemised quotation within 1 working day, B2B invoicing
Delivery nationwide — installation available for enterprise gear

Key specifications
Capacity	500 VA
Real power	300 W
Form	Tower
Network card slot	No
Battery replaceable	Yes

Full specifications ↓

Product details

APC Back-UPS 500, 230V (BK500EI)

300 Watts, 500 VA | Input & Output voltage 230V

Warranty
- 2 years Manufactorer Limited Warranty

Specifications

Specifications
Model	BK500EI
Output	Output Power Capacity:300 Watts / 500 VA Max Configurable Power:300 Watts / 500 VA Nominal Output Voltage:230V Output Frequency (sync to mains):47 - 63 Hz Topology:Standby Waveform Type:Stepped approximation to a sinewave Output Connections: (1) IEC 320 C13 (Surge Protection) IEC 320 C13 (3) IEC 320 C13 (Battery Backup) IEC 320 C13 (2) IEC Jumpers (Surge Protection)
Input	Nominal Input Voltage:230V Input Frequency:50/60 Hz +/- 3 Hz (auto sensing) Input Connections:IEC-320-C14 inlet Cord Length:1.83 meters Input voltage range for main operations:180 - 266V Input voltage adjustable range for mains operation:160 - 300V Maximum Input Current:7A Input Breaker Capacity:7.0 A
Batteries & Runtime	Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof Replacement Battery:RBC2 RBC™ Quantity:1
Communications & Management	Interface Port(s):USB Control panel: LED status display with On Line : On Battery : Replace Battery and Overload indicators Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering	Surge energy rating:310 Joules Filtering: Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449 Data Line Protection: Analog phone line for phone/fax/modem/DSL (RJ-45 connector)
Physical	Maximum Height:165.00 mm Maximum Width:91.00 mm Maximum Depth:284.00 mm Net Weight:6.32 KG Shipping Weight:7.05 KG Shipping Height:178.00 mm Shipping Width:241.00 mm Shipping Depth:368.00 mm Master Carton Units:2.00 Color:Beige SCC Codes:107 31304 01635 6 Units per Pallet:70.00
Environmental	Operating Environment:0 - 40 °C Operating Relative Humidity:0 - 95% Operating Elevation:0-3000 meters Storage Temperature:-15 - 45 °C Storage Relative Humidity:0 - 95% Storage Elevation:0-15000 meters Audible noise at 1 meter from surface of unit:40.00 dBA Online Thermal Dissipation:24.00 BTU/hr
Conformance	Regulatory Approvals: C-tick, CE, EN 50091-1, EN 50091-2, GOST, VDE Standard Warranty:2 years repair or replace
Sustainable Offer Status	RoHS:Compliant REACH: Contains No SVHCs PEP:Available in Documentation tab EOLI:Available in Documentation tab
* Features, Package Content and Specifications are subject to change without prior notification.*
