MikroTik CRS326-24S+2Q+RM | Switch | 24x SFP+, 2x QSFP, 1x RJ45 100Mb/s
Buy MikroTik CRS326-24S+2Q+RM | Switch | 24x SFP+, 2x QSFP, 1x RJ45 100Mb/s, Mikrotik from Printer Bullet - Everything for office. Fast & Free Home Delivery. Hi...
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ports SFP+ | 24x 10 Gbps |
| Ports QSFP+ | 2x 40 Gbps |
| Ethernet Ports | 1x 10/100 Mbps |
| Throughput | 320 Gbps |
| Switching Capacity | 640 Gbps |
Product details
If you are working with substantial amount of data – like providing Internet access or maintaining a huge data center – this is the perfect upgrade for your setup. CRS326-24S+2Q+RM is our first product with 40 Gbps QSFP+ ports for remarkably fast and stable fiber connection.
Overall it has two 40 Gbps QSFP+ ports and twenty four 10 Gbps SFP+ ports, which provides total nonblocking throughput of 320 Gbps and switching capacity of 640 Gbps with forwarding rate of 252 Mpps with most common packets.
CRS326-24S+2Q+RM is easy to manage – it has a full size USB port for configuration and dual power supply for redundancy – no unexpected downtime, your clients and colleagues will be thankful!
You can choose between our legendary feature-packed RouterOS for booting or a simpler, but still powerful SwOS. If you would like the ability to use routing and other Layer 3 features in your CRS, use RouterOS
SPECIFICATIONS
| Details | |
|---|---|
| Product code | CRS326-24S+2Q+RM |
| Architecture | MIPSBE |
| CPU | QCA9531 |
| CPU core count | 1 |
| CPU nominal frequency | 650 MHz |
| Dimensions | 443 x 200 x 44 mm |
| RouterOS license | 5 |
| Operating System | RouterOS or SwitchOS |
| Size of RAM | 64 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -20°C to 60°C |
POWERING
| Details | |
|---|---|
| Number of AC inputs | 2 |
| AC input range | 100-240 |
| Max power consumption | 69 W |
| Max power consumption without attachments | 42 W |
| Cooling type | 3 fans |
ETHERNET
| Details | |
|---|---|
| 10/100 Ethernet ports | 1 |
FIBER
| Details | |
|---|---|
| SFP+ ports | 24 |
| Number of 40G QSFP+ ports | 2 |
PERIPHERALS
| Details | |
|---|---|
| Serial console port | RJ45 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 1 |
CERTIFICATION & APPROVALS
| Details | |
|---|---|
| Certification | CE, EAC, ROHS |
| IP | IP20 |
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Ports SFP+ | 24x 10 Gbps |
| Ports QSFP+ | 2x 40 Gbps |
| Ethernet Ports | 1x 10/100 Mbps |
| Throughput | 320 Gbps |
| Switching Capacity | 640 Gbps |
| RAM | 64 MB |
| Storage | 16 MB FLASH |
| Power Consumption | 69 W max |
