Ubiquiti EdgeSwitch 48 Lite Managed Gigabit Switch with SFP+ (ES-48-Lite)
Buy Ubiquiti EdgeSwitch 48 Lite Managed Gigabit Switch with SFP+ (ES-48-Lite), Ubiquiti from Printer Bullet - Everything for office. Fast & Free Home Delivery....
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ports | (48) Gigabit RJ45 Ports, (2) SFP+ Ports, (2) SFP Ports |
| Throughput | 70 Gbps |
| Switching Capacity | 140 Gbps |
| Forwarding Rate | 104.16 Mpps |
| Power Consumption | 56W |
Product details
Advanced Switching Technology for the Masses. Build and expand your network with Ubiquiti EdgeSwitch™, part of the EdgeMAX® line of products. The EdgeSwitch is a fully managed, Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.
- (48) Gigabit RJ45 Ports
- (2) SFP+ Ports
- (2) SFP Ports
- (1) Serial Console Port
- Non-Blocking Throughput: 70 Gbps
- Switching Capacity: 140 Gbps
- Forwarding Rate: 104.16 Mpps
- Maximum Power Consumption: 56W
- Rack- or Wall-Mountable
- DC Input Option (Redundant or Stand-Alone)
Features:
| ES-48-LITE | |
|---|---|
| Dimensions | 443 x 43 x 286 mm (17.44 x 1.69 x 11.26") |
| Weight Rack-Mount Brackets Included Rack-Mount Brackets Excluded | 3.65 kg (8.05 lb) 3.56 kg (7.85 lb) |
| Total Non-Blocking Throughput | 70 Gbps |
| Switching Capacity | 140 Gbps |
| Forwarding Rate | 104.16 Mpps |
| Max. AC Power Consumption | 56W |
| Power Method AC | 100-240VAC/50-60 Hz, Universal Input DC 56W, 25 to 16V, with 2.5 mm DC Power Inline Connector |
| Power Supply | AC/DC, Internal, 56W DC |
| LEDs Per Port Serial Console Port RJ45 Data Ports SFP+/SFP Data Ports | N/A Speed/Link/Activity Speed/Link/Activity |
| Networking Interfaces | (48) 10/100/1000 Mbps RJ45 Ethernet Ports (2) 1/10 Gbps SFP+ Ethernet Ports (2) 1 Gbps SFP Ethernet Ports |
| Management Interface | (1) RJ45 Serial Port, Ethernet In/Out Band |
| Certifications | CE, FCC, IC |
| Rackmount | Yes, 1U High |
| ESD/EMP Protection | Air: ±24 kV, Contact: ±24 kV |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Shock and Vibration | ETSI300-019-1.4 Standard |
