Ubiquiti EdgeSwitch 16 port 150W Gigabit Switch (ES-16-150W)
Ubiquiti EdgeSwitch 16 port 150W Gigabit Switch (ES-16-150W) -
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ports | 16 Gigabit RJ45 + 2 SFP |
| Maximum Power Consumption | 150W |
| Switching Capacity | 36 Gbps |
| Non-Blocking Throughput | 18 Gbps |
| Interface | 10/100/1000 Mbps RJ45, 1 Gbps SFP |
Product details
Build and expand your network with Ubiquiti EdgeSwitch®, part of the EdgeMAX® line of products. The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks.
- (16) Gigabit RJ45 Ports
- (2) SFP Ports
- (1) Serial Console Port
- Non-Blocking Throughput: 18 Gbps
- Switching Capacity: 36 Gbps
- Forwarding Rate: 26.78 Mpps
- Maximum Power Consumption: 150W
- Supports POE+ IEEE 802.3at/af and 24V Passive PoE
- Rackmountable with Rack-Mount Brackets (Included)
Features:
| ES-16-150W | |
|---|---|
| Dimensions | 443 x 43 x 221 mm (17.44 x 1.69 x 8.70") |
| Weight With Mount Brackets | 2.80 kg (6.17 lb) 2.89 kg (6.37 lb) |
| Total Non-Blocking Line Rate | 18 Gbps |
| Max. Power Consumption | 150W |
| Power Method | 100-240VAC/50-60 Hz, Universal Input |
| Power Supply | AC/DC, Internal, 150W DC |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| LEDs Per Port RJ45 Data Ports SFP Data Ports | PoE, Speed/Link/Activity Speed/Link/Activity |
| Networking Interfaces | (16) 10/100/1000 Mbps RJ45 Ports (2) 1 Gbps SFP Ports |
| Management Interface | UART Console Out-of-Band, Ethernet In-Band |
| PoE Interfaces | PoE+ IEEE 802.3af/at (pins 1, 2+; 3, 6-) 24VDC Passive PoE (pins 4, 5+; 7, 8-) |
| Voltage Range 802.3at Mode 24V Passive PoE | 50-57V 20-27V |
| Max. Wattage per Port PoE+ Passive PoE | 34.2W 17W |
| Rack-Mount | Yes, 1U High |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Ports | 16 Gigabit RJ45 + 2 SFP |
| Maximum Power Consumption | 150W |
| Switching Capacity | 36 Gbps |
| Non-Blocking Throughput | 18 Gbps |
| Interface | 10/100/1000 Mbps RJ45, 1 Gbps SFP |
| Power Input | 100-240VAC/50-60 Hz |
| Operating Temperature | -5 to 40°C |
| Dimensions | 443 x 43 x 221 mm |
