Ubiquiti Networks UniFi 16-Port Managed Gigabit PoE Switch with SFP (USW-16-POE)
Buy Ubiquiti Networks UniFi 16-Port Managed Gigabit PoE Switch with SFP (USW-16-POE), Ubiquiti from Printer Bullet - Everything for office. Fast & Free Home Del...
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ports | 16x Gigabit RJ45 + 2x 1G SFP |
| PoE Ports | 8x 802.3at PoE+ |
| Total PoE Supply | 42W |
| Switching Capacity | 36 Gbps |
| Throughput | 18 Gbps |
Product details
- (1) 1.3" LCM color touchscreen with AR switch management
- (8) GbE, 802.3at PoE+ RJ45 ports
- (8) GbE RJ45 ports
- (2) 1G SFP ports
- 42W total PoE supply
- Fanless, silent cooling
The Switch 16 PoE (USW 16 PoE) is a fully managed switch with (16) GbE RJ45 ports, including (8) GbE, 802.3at PoE+ ports, and (2) 1G SFP ports. The versatile USW 16 PoE provides Gigabit PoE links to Ethernet devices while also supplying Gigabit fiber uplink options fit for an enterprise network. The switch also offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate), and features a 1.3" LCM color touchscreen that concisely displays key system and connection insights.
Additionally, with its 7.9" depth, it's easy to mount this compact, fanless switch in a SOHO rack cabinet. This switch can also be monitored or configured from anywhere with the powerful, intuitive USW Network web application and mobile app.
Features:
Managed with the USW Network application: Version 5.11.27 and later
| Mechanical | |
|---|---|
| Dimensions | 424.4 x 200 x 43.7 mm (16.71 x 7.87 x 1.72") |
| Weight With Rackmount Brackets | 2.80 kg (6.17 lb) 2.89 kg (6.37 lb) |
| Interfaces Networking Management | (16) 10/100/1000 RJ45 Ports (2) 1G SFP Ethernet Ports Ethernet In-Band |
| Total Non-Blocking Throughput | 18 Gbps |
| Switching Capacity | 36 Gbps |
| Forwarding Rate | 26.78 Mpps |
| Power Method | 100-240VAC/50-60 Hz, Universal Input |
| Power Supply | AC/DC, Internal, 60W |
| Supported Voltage Range | 100 to 240VAC |
| Max. Power Consumption (Excluding PoE Output) | 18W |
| LEDs RJ45 Data Ports SFP Data Ports | PoE; Speed/Link/Activity Link/Activity |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
| PoE | |
| Total Available PoE | 42W |
| PoE Interfaces Ports 1-8 | POE+ IEEE 802.3af/at (pins 1, 2+; 3, 6-) |
| Max. PoE Wattage per Port by PSE 802.3at | 32W |
| Voltage Range 802.3af Mode | 44-57V |
| Voltage Range 802.3at Mode | 50-57V |
- Delivery & professional installation
- Configuration & migration
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Ports | 16x Gigabit RJ45 + 2x 1G SFP |
| PoE Ports | 8x 802.3at PoE+ |
| Total PoE Supply | 42W |
| Switching Capacity | 36 Gbps |
| Throughput | 18 Gbps |
| Power Consumption | 18W |
| Dimensions | 424.4 x 200 x 43.7 mm |
| Weight | 2.80 kg |
