Ubiquiti UF-WIFI point-to-multipoint WiFi router with a GPON WAN port and (4) Gigabit RJ45 ports (UF-WIFI)
Buy Ubiquiti UF-WIFI point-to-multipoint WiFi router with a GPON WAN port and (4) Gigabit RJ45 ports (UF-WIFI), Ubiquiti from Printer Bullet - Everything for of...
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| WAN Port | 1 GPON SC/APC |
| LAN Ports | 4 Gigabit RJ45 |
| WiFi | 802.11n 300 Mbps |
| Downstream Speed | 2.4 Gbps |
| Upstream Speed | 1.2 Gbps |
Product details
- High-Performance GPON CPE
- Up to 2.4 Gbps Downstream and 1.2 Gbps Upstream
- Supports up to 20 km GPON Links
- Powerful Layer 2/3 Management Features
- (1) GPON WAN Port
- (4) RJ45 Gigabit LAN Port
- Powered via supplied PSU or passive PoE
- WiFi 802.11n with internal antennas
UFiber WIFI is a robust, high‐performance GPON CPE that offers routing, four LAN ports, and Wi‐Fi. It is powered by 24V passive PoE or a 24V, 0.5A power adapter.
Features:
| UFiber WiFi | |
|---|---|
| Dimensions | 126.34 x 126.09 x 31.65 mm (4.97 x 4.96 x 1.25") |
| Weight | 190 g (6.70 oz) |
| Networking Interfaces | (1) SC/APC, GPON WAN (4) Gigabit RJ45, Ethernet LAN (1) Wi-Fi, 802.11n |
| Networking Interface Speeds GPON WAN, ITU G.984 LAN Wi-Fi | 2.4 Gbps Down, 1.2 Gbps Up 10/100/1000 Mbps 300 Mbps |
| Management Interface | In-Band Ethernet PON |
| Normal Optical Power Range | TX (Class B+): 1.5 to 5 dBm RX: -28 to -8 dBm |
| Power Method | DC Jack, 24VDC 24V Passive PoE (Pins 4, 5+; 7, 8-) |
| Power Supply | 100-240VAC / 50-60 Hz Universal AC/DC 24V / 0.5A |
| Max. Power Consumption | 7W |
| Supported Voltage Range | 20 to 28V |
| Processor Specs | MIPS, 900 MHz |
| Memory Information | 256 MB DDR |
| Button | (1) Reset |
| Operating Temperature | -10 to 45° C (14 to 113° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| WAN Port | 1 GPON SC/APC |
| LAN Ports | 4 Gigabit RJ45 |
| WiFi | 802.11n 300 Mbps |
| Downstream Speed | 2.4 Gbps |
| Upstream Speed | 1.2 Gbps |
| Power | 24V passive PoE or 24V 0.5A adapter |
| Memory | 256 MB DDR |
| Processor | MIPS 900 MHz |
