Ubiquiti UFiber OLT UF-OLT - 8 port GPON Optical Line Terminal Gigabit Passive Optical Network
Ubiquiti UFiber OLT UF-OLT - 8 port GPON Optical Line Terminal Gigabit Passive Optical Network -
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| GPON Ports | 8 |
| Maximum Clients | 1024 (128 per PON Port) |
| SFP+ Ethernet Ports | 2 (1G/10G) |
| Data Rate | 2.488 Gbps TX / 1.244 Gbps RX per Port |
| Maximum Distance | 20 km |
Product details
- 8 Gigabit Passive Optical Network Ports
- Supports up to 1024 Clients (128 per PON Port)
- Up to 2.488 Gbps TX and 1.244 Gbps RX
- Two 1G/10G SFP+ Ethernet Ports
- Flexible Layer 2/3 Management Features
- FastEthernet port for management
- Console serial port for management
UFiber OLT supports up to 128 ONU CPEs per GPON port with physical links of up to 20 km in distance. It also features SFP+ connectivity for uplinking. The UFiber OLT can be mounted in a 1U rack, mounted on a wall, or placed on a desktop. Management options include the Gigabit Ethernet port (out‑of‑band), RJ45 serial console port (CLI), and uplink (in‑band) – configured via the UFiber UI or UISP.
Features:
| UF-OL | |
|---|---|
| Dimensions | 442.4 x 285.6 x 43.7 mm (17.42 x 11.24 x 1.72") |
| Weight Without Mount Brackets With Mount Brackets | 4.400 kg (9.70 lb) 4.495 kg (9.91 lb) |
| Max. Power Consumption | 40W (Excluding SFP Transceivers) |
| Power Method | 110 - 240VAC Modular PSU |
| Power Supply | (1) Hot-Swappable AC/DC 100W PSU (Included) |
| Supported Voltage Range | AC Input: 100 to 240VAC |
| Button | Reset |
| Processor | MIPS 1004Kc 880 MHz Dual-Core |
| System Memory | 512 MB DDR3, 512 MB NAND |
| LEDs System PON Data Ports SFP+ Data Ports RJ45 (MGMT) Port | Status Link/Activity Link/ActivityLink/Activity Link/Activity |
| Data Ports Interfaces | (8) GPON Ports (2.488 Gbps TX/1.244 Gbps RX per Port) (2) 1G/10G SFP+ Ports |
| Serial Console Port Interfaces | (1) RJ45 Ethernet Port (1) RJ45 Serial Port |
| Rackmount | Yes |
| Operating Temperature | -10 to 45° C (14 to 113° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
| GPON SFP OLT Transceiver (UF-GP-B+ ) | Single Fiber, SM SC/UPC, 20 km, 1490 nm TX/1310 nm RX, ITU-T G984.2 Class B+ |
- Delivery & professional installation
- Configuration & migration
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| GPON Ports | 8 |
| Maximum Clients | 1024 (128 per PON Port) |
| SFP+ Ethernet Ports | 2 (1G/10G) |
| Data Rate | 2.488 Gbps TX / 1.244 Gbps RX per Port |
| Maximum Distance | 20 km |
| Power Consumption | 40W (Excluding SFP Transceivers) |
| Operating Temperature | -10 to 45°C |
| Dimensions | 442.4 x 285.6 x 43.7 mm |
