Ubiquiti USW-Enterprise-8-PoE Layer 2 switch with (8) 10G SFP+ ports
Buy Ubiquiti USW-Enterprise-8-PoE Layer 2 switch with (8) 10G SFP+ ports, Ubiquiti from Printer Bullet - Everything for office. Fast & Free Home Delivery. High...
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ports | (8) 2.5GbE PoE+ RJ45 ports and (2) 10G SFP+ ports |
| Layer | Layer 3 |
| Switching Capacity | 80 Gbps |
| Total PoE Power | 120W |
| Dimensions | 200 x 248 x 44 mm |
Product details
The Switch Enterprise 8 PoE (USW Enterprise 8 PoE) is a fully managed, Layer 3 switch with (8) 2.5GbE, PoE+ RJ45 ports and (2) 10G SFP+ ports.The USW Enterprise 8 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. This switch can be monitored or configured from anywhere with the powerful, intuitive UAP Network web application and mobile app.
Features:
- (1) 1.3" LCM color touchscreen with AR switch management
- (8) 2.5GbE, PoE+ RJ45 ports
- (2) 10G SFP+ ports
- 120W total PoE supply
- Wall-mountable (kit included)
| Mechanical | |
|---|---|
| Dimensions | 200 x 248 x 44 mm (7.9 x 9.8 x 1.7") |
| Weight | 2.4 kg (5.29 lb) |
| Enclosure Materials | Polycarbonate |
| Mount Material | Polycarbonate |
| Hardware | |
| Total Non-Blocking Throughput | 40 Gbps |
| Switching Capacity | 80 Gbps |
| Forwarding Rate | 59.52 Mpps |
| Max PoE Power | 120W |
| Power Method | (1) 100-240VAC, 2A Max., 50/60 Hz, Universal Input |
| Power Supply | AC/DC, Internal, 150W |
| Management Interface | Ethernet In-Band |
| Networking Interfaces | (8) 1/2.5 GbE RJ45 |
| SFP+ Interfaces | (2) 1/10 Gbps SFP+ |
| PoE Interfaces | (8) PoE/PoE+ (Pins 1, 2+; 3, 6-) |
| Max. PoE+ Wattage per Port by PSE | 32W |
| Voltage Range PoE Mode | 44 - 57V |
| Voltage Range PoE+ Mode | 50 - 57V |
| Services | SMB Layer 3* PoE GbE Switch * Layer 3 feature will be available in the future firmware release. |
| LCM Display | (1) 1.3" Touchscreen Bootup Animation: Bootup in Progress Firmware Upgrade Icon: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Operating Temperature | -5 to 45° C (23 to 113° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| Ethernet | White: Link or Activity |
| SFP+ | White: Link or Activity |
- Delivery & professional installation
- Configuration & migration
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Ports | (8) 2.5GbE PoE+ RJ45 ports and (2) 10G SFP+ ports |
| Layer | Layer 3 |
| Switching Capacity | 80 Gbps |
| Total PoE Power | 120W |
| Dimensions | 200 x 248 x 44 mm |
| Weight | 2.4 kg |
| Operating Temperature | -5 to 45°C |
| Display | 1.3" LCM color touchscreen |
