Ubiquiti USW-Pro-24 Layer 3 switch with (24) GbE RJ45 ports and (2) 10G SFP+ ports
Ubiquiti USW-Pro-24 Layer 3 switch with (24) GbE RJ45 ports and (2) 10G SFP+ ports -
- Genuine unit through the authorised channel — manufacturer warranty
- Itemised quotation within 1 working day, B2B invoicing
- Delivery nationwide — installation available for enterprise gear
| Ports | (24) GbE RJ45 ports and (2) 10G SFP+ ports |
| Switching Capacity | 88 Gbps |
| Total Non-Blocking Throughput | 44 Gbps |
| Forwarding Rate | 65.472 Mpps |
| Max Power Consumption | 30W |
Product details
- (1) 1.3" LCM color touchscreen with AR switch management
- (24) GbE RJ45 ports
- (2) 10G SFP+ ports
- (1) USP RPS DC input
- Near-silent cooling
- Layer 3 switching features
The Switch Pro 24 (USW Pro 24) is a fully managed switch with (24) GbE RJ45 ports and (2) 10G SFP+ ports. The USW Pro 24 combines a rich set of Layer 2 features with advanced Layer 3 tools including inter-VLAN routing, static routing, and a DHCP server. The USW Pro 24 is an ideal aggregation and access layer switch for any USW system. It combines innovative, near-silent cooling capability with SmartPower RPS (USP RPS) power redundancy. The switch can also be monitored and configured from anywhere with the powerful, intuitive UAP Network web application and mobile app.
Features:
Managed with the UAP Network application: Version 5.12.11 and later
| Mechanical | |
|---|---|
| Dimensions | 442.4 x 285.4 x 43.7 mm (17.42 x 11.24 x 1.72") |
| Weight With Brackets | 3.50 kg (7.72 lb) 3.59 kg (7.92 lb) |
| Interfaces Networking Management | (24) 10/100/1000 RJ45 Ports (2) 1/10G SFP+ Ethernet Ports Ethernet In-Band |
| Total Non-Blocking Throughput | 44 Gbps |
| Switching Capacity | 88 Gbps |
| Forwarding Rate | 65.472 Mpps |
| Power Method Universal Input USP RPS DC Input | 100-240VAC, 50/60 Hz 11.5VDC, 2.61A |
| Power Supply | AC/DC, Internal, 36W |
| Voltage Range | 100 to 240VAC |
| Max Power Consumption | 30W |
| LEDs RJ45 Data Ports SFP+ Data Ports | Speed/Link/Activity Link/Activity |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 45° C (23 to 113° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
- Delivery & professional installation
- Configuration & commissioning
- Manufacturer warranty handling
- Annual maintenance & managed services (MSP)
Engineering by our services division, Ryzen ESolutions — Network design & engineering →
Talk to the engineers who install this equipment — free sizing advice, no obligation.
Specifications
| Printing & Imaging Specs | |
|---|---|
| Ports | (24) GbE RJ45 ports and (2) 10G SFP+ ports |
| Switching Capacity | 88 Gbps |
| Total Non-Blocking Throughput | 44 Gbps |
| Forwarding Rate | 65.472 Mpps |
| Max Power Consumption | 30W |
| Operating Temperature | -5 to 45° C |
| Weight | 3.50 kg |
| Dimensions | 442.4 x 285.4 x 43.7 mm |
